Down Type Manual Glue Gun GH4000

Model: GH4000
The manual glue gun GH4000 combines ergonomic design and high-pressure operation to dispense medium-and low-viscosity industrial and automotive sealants and adhesives. For precise control of low viscosity materials.
Light and comfortable appearance
The manual glue gun GH4000 is made of alloy steel, which is small and light, and can withstand high pressure.

Specifications

Model	Rated working pressure (MPa)	Rated working temperature (℃)	Gun body material	Valve core structure	Flow parameter (LPM)	*Recommended fluid viscosity (Pas)**	Weight (g)	Notes
GH4000	41	15~50	AL	Alloy Ball	≥4.5	≤300	580
Notes					14MPa, 20# oil		Nozzle not included

Item	GH4000	Notes
Paint interface	1/2npt (f)	Standard order model: GH4000
	3/8npt (f)	Derivative order model: GH4000-N03
	1/4npt (f)	Standard order model: GH4000-N02
Threaded nozzle interface	1/4npt (f)	Standard D2.5 round nozzle
Press-fit nozzle interface	D13.8*D17 (Press-fit steps)	Standard press nut
Wet area material	FKM; PTFE; UPR; SST; CU; AL; Chrome-manganese steel; Tungsten steel
Installation direction	Any
